GPS SYNCHRONIZE CURRENT INTERRUPTER
The GPS based Timer is designed for applications requiring Time Synchronized events at multiple locations. The units consist of a GPS module with an external antenna to communicate with satellite based GPS system. The internal Real Time Clock (RTC) is synchronized within 1 millisec accuracy with the GPS clock signal at regular intervals.
Features and Benefits:
1) GPS Based current interrupter timer size (96X96mm)2) Real time on/off Timer with High Accuracy for perfect synchronization.
3) Specially designed Timer for carrying out on/Off Cathodic Protection surveys using the current interruption technique
4) LCD display and 4-key keypad for ease of programming and for displaying the information about various modes & time periods is provided on the front panel.
5) Facility for programming of ON & OFF cycle time of DC current interruption from 0.1 sec to 99.9 seconds.
6) Micro-controller based Digital Circuitry
7) The Start and Stop of the timing cycle is also programmable and is controlled by the built-in real time clock in the Timer
8) Interruption START and STOP time is user programmable.
