1) Voltage Range DC 0-1000V with auto ranging from mV volt to V.
2) Voltage Range AC 0-1000V with auto ranging from mV to V.
3) Current Range DC 0-10 amp.
4) Current Range AC 0-10 amp.
5) In built GPS for Time stamp and location.
6) External SD card storage for Data Logging upto 32GB supported (FAT32 format only).
7) Alphanumeric LCD for complete Information display and Parameter setting.
8) LCD color white backlit and black characters.
9) Easy to use interface for setting parameters using four switches.
10) Powered by a 3.7V Li ion rechargeable battery.
11) Auto sleep Function.
12) Data logging rate @ 1 second
13) Sampling rate 100ms i.e. 10 samples logged every second.
14) External GPS antenna Connection for remote areas and offsite locations.
15) NOTE: It’s highly recommended to attach the antenna before switching on
the device.
